Torque: Up to 4,200N·m Rotation: 180° Counterbalance Valve: Optional Interchangeable Brands: HELAC, HKS, and MOVECO Warranty: 2 years (limited)
Send Inquiry

Product Description

Feature and Benefits
⚡ Powerful High torque, high bearing capacity.
🛡️ Durable Moving parts enclosed, suitable for harsh environments.
📏 Compact High power density, fits in tight spaces.
🔒 Holds Position Zero internal leakage, smooth operation, no external brake required.
🛠️ Simplifies Eliminates bearings, linkages & brackets, reduces bill of materials.
🔄 Backdrives in Overload Hydraulic fuse, prevents mechanical damage.
Specifications
Drive Torque Comparison of WL20 Series Hydraulic Rotary Actuators
Other Parameters
Model/Specifications WL20-005 WL20-009 WL20-016 WL20-027 WL20-042
HOLDING TORQUE (N·m) 500 900 1600 2680 4200
MAX STRADDLE MOMENT DISPLACEMENT CAPACITY (N·m) 1300 2400 4400 7100 10500
MAX CANTILEVER MOMENT CAPACITY (N·m) 2500 4500 10200 16400 31600
RADIAL CAPACITY (kg) 1380 2130 4190 5580 9530
AXIAL CAPACITY (kg) 500 680 100 1400 1770
DISPLACEMENT 180° (cc) 132 234 436 726 1070
WEIGHT 180° (kg) 12.5 17 30 51 77
Mounting Type Foot Foot Foot Foot Foot
Output Mode Front Flange Front Flange Front Flange Front Flange / Double Flanges Front Flange / Double Flanges

Note: All the parameters are tested @21Mpa.

Applications & Market
Agricultural Machines Aerial Working Platforms Excavators Garbage Trucks Drilling Machines Construction Attachments Energy Industry Marine
Application scenarios
Product Packing
Product Packing Details
Frequently Asked Questions
What are the primary advantages of the WL20 series rotary actuators?
The WL20 series offers high torque, high bearing capacity, and a compact design, making it ideal for tight spaces and harsh environments.
Is an external brake required for these actuators?
No, these actuators feature zero internal leakage, which allows them to hold positions smoothly without the need for an external brake.
How does the actuator handle overload conditions?
It is equipped with a hydraulic fuse that allows for backdriving in overload conditions, effectively preventing mechanical damage.
What is the standard mounting type for the WL20 series?
The standard mounting type for all models in the WL20 series (from 005 to 042) is the Foot mount.
What output modes are available?
Available modes include Front Flange for smaller models, while larger models like the WL20-027 and WL20-042 support both Front and Double Flanges.
Can these actuators be used in marine environments?
Yes, the moving parts are fully enclosed, making them highly durable and suitable for harsh environments including marine and energy industries.
