Weitai Hydraulic
1 / 4
| Parameter | Specification Value |
|---|---|
| Rotation | 180°, 360° |
| Output Mode | Front Flange |
| Mounting | Flange |
| Drive Torque (Nm@21Mpa) | 1600 |
| Holding Torque (Nm@21Mpa) | 5700 |
| Max Cantilever Moment Capacity (Nm) | 9000 |
| Radial Capacity (Kg) | 4980 |
| Axial Capacity (Kg) | 4980 |
| Displacement 180° (cc) | 552 |
| Displacement 360° (cc) | 1105 |
| Weight 180° (Kg) | 43.3 |
| Weight 360° (Kg) | 54.5 |
| Dimension Feature | Value (mm / Qty) |
|---|---|
| D1 Mounting Flange Dia | 148 |
| D2 Housing Dia | 198 |
| F1 Mounting Hole | M12×1.75 |
| F2 Qty of Mounting Holes | 12 |
| F3 Bolt Circle Dia of Shaft Flange | 127 |
| F4 Mounting Hole | M12×1.75 |
| F5 Qty of Mounting Holes | 12 |
| F6 Bolt Circle Dia of Endcap Flange | 175 |
| F7 Shaft Through-Hole Dia | 45.7 |
| H1 Height | 129 |
| L1 Length 180° / 360° | 224 / 311 |
| L2 Length 180° / 360° | 221 / 308 |
| L3 Distance To Valve 180° / 360° | 38.6 / 60.2 |
| P1, P2 Port | ISO-1179-1/BSPP ‘G’ series, 1/8~1/4 |
| V1, V2 Port | ISO-11926/SAE series, size 7/16 |
*Specification charts are for general reference only, please consult drawing for actual values and tolerances.
